SPECIFICATIONS FOR PROCON
TEMPERATURE |
Operating.....-20°F to 158°F (-29°C to 70°C) |
| Storage........-45°F to 176°F (-45°C to 80°C) | |
| SHOCK | Operating.....3G
|
| Storage........50G | |
VIBRATION |
Operating.....3G
|
| Storage........3G | |
| CORROSIVE GAS | NOT ACCEPTABLE |
| SALT SPRAY | NOT ACCEPTABLE |
| OPERATING VOLTAGE | 10-30 Volts |
| POWER CONSUMPTION | 500mWatt |
| REVERSE POLARITY PROTECTION | Yes |
| LOAD DUMP | Meets SAE J1113, 3 positive 80V transients One minute intervals |
PROCON INTERFACE
| INPUT | Accepts either J1939
or J1587/J1708 (set at factory)
|
| OUTPUT | Can be either RS485 or RS232 (set at factory)
|
| OUTPUT PROTOCOL | Can be Modbus RTU, Allen Bradley, DF-1, or custom
protocol (set at factory)
|
